Comprensión de un estudio realizado en la mica-epoxi para placas de circuitos. El estudio consistió en pruebas de resistencia para medir el desgaste en el tiempo del material y así determinar su tiempo de vida aproximado.

Chart of subatomic particles

LaTeX template I've used extensively for Engineering homeworks.

The aim of the experiment is to study elliptically polarized light using a Fresnel rhomb and to determine the ratio of semi major axis to the semi minor axis of the various elliptically polarised light forms for different angles of plane polarised incidence at the rhomb

The fundamental necessity for water is a widespread issue affecting many communities across the globe. In this project, our team sought to provide an innovative solution to this problem for a small community with access to a relatively close source of flowing water. Resultant flow rate of water was calculated to be 0.498 L/min. Stress and strain analysis on individual subsections of the system were as follows: -44.2 MPa for bending moment in the rod; -7.04 MPa for shear stresses in the rod of the axis; -8.88E-5 for shear strain in the rod ; -1.11 MPa and .429 MPa of shear stresses in the L brackets; -0.123 MPa for radial stress of spiral, -0.422 MPa for hoop stress of spiral, -2.10 MPa for bending moment of spiral, and -0.176 MPa for the maximum shear stress of the spiral pump on the rotating wheel. The focus of the design remained fixated on water acquisition; however, further additions can be made for water purification.

Nuclear Science and Techniques (NST) is an international, peer-reviewed scientific journal sponsored by Shanghai Institute of Applied Physics, Chinese Academy of Sciences and the Chinese Nuclear Society. It was established in 1990 as a quarterly journal and had been changed to a monthly frequency in 2017. The journal is devoted to applied nuclear physics; fundamental study of nuclear energy; application of nuclear techniques in various fields; radiochemistry and radiation chemistry; nuclear instruments and methods. The publication of the journal is aimed at enhancing academic exchange between Chinese and foreign scientists, and at promoting development of nuclear science and techniques and their applications. NST has been indexed by SCI-E, CA in US, SA in UK and РЖ in Russia. The editor-in-chief is Prof. Yu-Gang Ma.

LaTeX Template for Easily Writing Review Notes as shown in this example.

TP thermodynamique

The aim of this laboratory work is to design a strut/bracket assembly for aircrafts. Experiments are carried out to determine mechanical properties of certain materials.The material chosen is Mild Steel. Given the possible condition experienced by the material and the safety factor, the dimensions for the designs of the strut/bracket assembly for aircrafts are obtained to avoid failure by yield or fracture. The diameter of the pin, d ,which is subjected to shear stress should be larger than 14.56mm. The diameter of the rod, D, should be larger than 12.74mm. The thickness of the rod would be 10mm.
